Model: DPP-160 Production capacity: 15-50Cut/min Power: 7.5kw Specifications: 3300×750×1900mm
Introduction
Introduction:
Application：
The design structure of DPP-160 series automatic blister packing machine is meeting the standard requirements of GMP,cGMP and the design principle of ergonomics.It adopts advanced smart driver and control technology.
SINPAK packing machine is very suitable for your market and meet your needs.It can help you solve complex problems and face the future competition.As to the packing technology,XlNFEI can provide you integrated and extensive technical tips,strong competitiveness and rich experience.
The Technique Data:
Main Technical Data
Cutting Frequency:15-50Cut/min
Material Spec.
Forming Material:width:180mm Thickness:0.15-0.5mm
Stroke Adjusting Area
Stroke Area:50-130mm
Output
8000-12000 Blisters/h(if 4 Blisters/mold)
Main Function
Forming,Sealing,Cutting Once Completed;Stepless Frequency Conversion;PLC Control
Max.Forming Depth
20mm
Max.Forming Area
180×130×20mm
Power
380V 50hz
Total Power
7.5kw
Air-compress
0.5-0.7mpa
Compressed-air Consumption
≥0.22m³/h
Cooling Water Consumption
Circulating Cooling By Chiller
Noise
75db
Dimension(L×W×H)
3300×750×1900mm
Weight
1500kg
Motor Fm Capability
20-50hz
